IEC Single Phase Smart Meter Device

Features Tech Specs Datasheets
Proven, Secure, Multi-Application
Secure: built on industry leading security features Reliable: provides a 20 year life Extensible: connects to local devices such as in-home displays
Proven, Secure, Multi-Application
Open Standard, Reliable Platform
Smart grid device and revenue-grade commercial smart meter. Collects industry leading variety of grid health data elements as well as provides alarming on deviation of power distribution service levels. 4x16 load profiles for flexible collection of sensing and metering data for grid health management and smart metering applications.
Gen 4 Single Phase Meter Features Gen 4 Single Phase Meter Features
Enhanced Security UC-3 Compliant Disconnect Switch Larger Memory for More Data Storage Multiple MEP Connections and Flexible I/O options Cutting Edge Host Processor for Future Smart Grid Application Expansion Innovative and Customer Friendly Mechanical Design
Protect Revenue and Reduce Operational Costs Protect Revenue and Reduce Operational Costs
Forward, reverse, net active energy, kvarh import/export, and four-quadrant kvarh measurements enable customer micro-generation sources and power quality monitoring. Tampering attempts are detected on cover removal and magnetic field presence. All events are detected and logged - even during power failures - and then securely communicated in a timely manner. Energy measuring technology is highly resistant to DC magnetic fields.
Proven, Reliable Choice Proven, Reliable Choice
Millions of meters deployed with 20 year service life. Each meter acts as repeater to reach other meters and establish a power line mesh network that shows the real topology of the low-voltage distribution system.
A Smart Meter and Powerful Grid Sensor in One A Smart Meter and Powerful Grid Sensor in One
Load profiling; billing for time-of-use, prepay, and optional max demand; power-quality analysis of 271 grid health measurement elements; remote-controlled disconnect/reconnect switch; comprehensive display, home area networking support.
Open Communications for Expandability and Interoperability Open Communications for Expandability and Interoperability
Optional serial multipurpose expansion port (MEP) allows secure hardware extensions for communication with in home devices as well as gas, heat and water meters. OSGP certified, delivering data at industry leading availability rates enabling smart grid applications.
Technical Specs
Accuracy Active: Class 1 certified to IEC 62053-21, Class 0.5S certified to IEC 62053-22 upon request, Class B certified to EN 50470-3 (MID), MID Class C certified to EN 50470-3 upon request
Reactive: Class 2 certified to IEC 62053-23, Class 1 certified to IEC 62053-24 upon request




Operating temperature -40˚ to +70˚ C





Voltage 120V to 240V phase-to-neutral, range -20% to +15% (Gen 4 MTR1000 Series)
120V to 240V phase-to-phase, range -20% to +15% (Gen 4 MTR1020 Series)
220V to 240V phase-to-neutral, range -20% to +15% (Gen 3.2 MTR1000 Series)
220V to 240V phase-to-phase, range -20% to +15% (Gen 3.2 MTR1020 Series)





 Frequency 50Hz / 60Hz, +/- 5% (Gen 4)
50Hz, +/- 5% (Gen 3.2)





Service Type 1-phase, 2-wire
